CERRXIAN Infrared Remote Control Extender Cable, IR Repeater Hidden Cable with IR Signal Receiver & IR Emitter & USB Power Cable (2M/6.5ft)

Do many cable boxes, A/V receivers, media players, or other IR-controlled equipment confuse your entertainment center? If you only have a short distance to move them to a closed position, but this prevents you from using them with a remote control, using CERRXIAN Infrared Remote Control Extender Cable cable is the ideal solution to your problem! Home theater accessory repeats the IR signal to a DVD player, STB box, Receiver or other A/V source with an IR sensor; Route the infrared remote control extender cable out of sight with a wall mounted TV; Install the IR Transmitter end in a concealed equipment closet to hide a catv box and control it remotely.Specifications:1.Connector Type: IR Signal Receiver x1 & IR Emitter x1 & USB x1 2.Receive Frequency Range: 20KHZ to 60KHZ3.Receive Range: 10m/32ft4.Emitters Range:10cm/3.9inch5.Cord Length (USB to IR Receiver): 1.4m/4.5ft;Cord Length (IR Receiver to IR Emitters): 2m/6.5ft6.Signal receiving angle 180°7.USB output: 5V8.LED flashes to confirm signal receptionHOW TO USE:1.Plug the USB into your TV, set top box or a 5V USB wall adapter(adapter not included) for supply power.2.Paste the IR emitter(small end) on the signal receiver window receiving point of the appliances(up to 10cm/3.9inch).1.Stick the IR receiver(big end) next to TV screen (Not on the screen) orin the line of sight of your remote control (up to 10m/ 32ft).4.Check the battery in your remoteImportant Notes Test the cable before attaching with the adhesive backing Check that the USB TV port provides 5V USB power or use a USB wall charger Not compatible with a set-top box using (RF) radio frequency signals Bright sunlight or CFL light bulbs can cause interference

• IR REMOTE CONTROL - Simplify your entertainment center by hiding your cable box, receiver, amp, Roku & other IR controlled devices hidden behind cabinet doors and a wall. No more boxes placing on the shelf or leaving cabinet doors open when your watching TV just so you can use your remote control!This was a very economical and effective way to make it happen.
• EASY TO USE - Plug the USB into your TV, set top box or a 5V wall adapter(adapter not included) for supply power, then paste the IR emitter(small end) using it's own adhesive over on the device with an IR sensor you wish to control(up to 10cm/3.9inch).Lastly, place the IR receiver(big end) end in the line of sight of your remote control (up to 10m/ 32ft).
• WIDE BAND TECHNOLOGY - 20-60KHZ,works on most infrared control devices(not RF)! Suitable for infrared remote control, infrared extender, DVD player, STB box,Cisco,DirecTV,Roku, Sony, Yamaha,etc.
• EXCELLENT SIGNAL RANGE - 180 degree IR receiving angle provides enough space for your remote control to get the right angle. The remote control signal receives a real-time response and moves forward quickly without delay.
• HIDDEN DEVICES - Devices that require remote control must be placed where you cannot directly control your remote control. Otherwise, the signal from the remote control and the forwarded remote control signal will be sent to the set-top box at the same time. Signals out of sync can interfere with each other and cause them to stop working.
